• VLAN ID: 10
• VLAN Priority: 0
• Connection Type: Dynamic IP (DHCP)

• Connect the WAN (Internet) port of the router to the first port on your ONT using an Ethernet cable.
• Ensure the router is powered on and connected to your computer or smartphone via Wi-Fi or a LAN cable.

• Open a web browser on a connected device and type the default IP address 192.168.1.1 or 192.168.2.1 or 192.168.0.1 (depending on the default settings of your router) into the address bar.
• You will be prompted to log in. The default credentials are usually:
  • Username: admin
  • Password: admin
    • If you have changed the default credentials and cannot remember them, proceed to Step 7 for resetting the router.

Once logged in, follow these steps to configure the required settings:

1. Navigate to Advanced Settings > Internet Settings > WAN Settings.
2. In the WAN settings section, set Connection Type to Dynamic IP, IPoE (IP over Ethernet), Automatic IP, or DHCP.
3. Scroll down to find the VLAN Settings (or VLAN Tagged Traffic Filter).
   • Set VID to 10.
   • Set PRIO to 0.

• After entering the VLAN and DHCP settings, click Save or Apply to confirm the changes.
• The router may restart to apply the new settings. Wait a few minutes for the restart to complete.

• Once the router has restarted, check the status of your Internet connection by looking at the WAN/Internet LED indicator on the router. It should be solid green.
• On your connected device, try accessing a website to confirm that your connection is active.

If your Internet connection is not working:

1. Restart both the ONT and the router by unplugging them for 30 seconds and plugging them back in.
2. Double-check the VLAN and Dynamic IP (DHCP) settings in the router’s configuration.
3. Ensure that the Ethernet cable is securely connected to the correct ports (first port on the ONT and the WAN port on the router).

If you cannot access the router due to forgotten login credentials or misconfiguration, reset the router to factory settings:

1. Find the reset button at the back of the router.
2. Press and hold the reset button for about 10-15 seconds using a pin or paperclip.
3. Release the button once the router’s lights start flashing. The router will reboot and return to factory settings.
4. Log in using the default credentials (admin/admin) and repeat the configuration process from Step 2.

If you are still unable to connect, please reach out to our support team at [email protected] for further assistance.
